Sample 9 Dupont female terminal cable

  • Sample 9
Wire Harness,Mini Coaxial Cable < Sample 9 OEM / ODM

Features: small screw type
Temperature range: -65~+165
Durability: 500 times
PLUG inner diameter/JACK outer diameter: 6.5mm/5.4mm
Electrical performance:
Characteristic impedance: 50 ohm
Working voltage: 335Vrms
Frequency range: 0-12.4GHz (soft cable)/0-18GHz (semi-rigid cable)
Medium withstand voltage: 1000Vrms
Contact resistance: inner conductor 3mOhm, outer conductor 2mOhm
Insulation resistance: >5000 megohm
Insertion loss: 0.15dB (6GHz)
RF leakage: -60dB/-90dB (flexible cable/semi-rigid cable)@2-3GHz
VSWR: straight flexible cable 1.15+0.02f(GHz)
Bend flexible cable 1.20+0.03f(GHz)
Curved semi-rigid cable 1.05+0.01f(GHz)
Curved semi-rigid cable 1.10+0.01f(GHz)
Good quality, welcome to contact us!

Competitive Price:
Place of Origin: Taiwan
Sales Method: Export, Manufacture, OEM/ODM
Payment Term: T/T, L/C, Western Union
Safety/Quality Approvals: Quality system meets ISO 9002 standard & UL verification
