Product Description

Type C male to DP male to male cable

Product Description :
Type C male to DP male to male cable
Type-C male to DP male cable is an efficient and multi-functional cable, specially designed for connecting devices with Type-C interface to DisplayPort screens.

*4K@60Hz resolution: Supports up to 4K resolution and can achieve a refresh rate of 60Hz, providing extremely high video quality and suitable for image and video editing, gaming and other needs.
*Same screen/expanded dual mode: The same content can be displayed on the same screen or the screen can be extended to provide a more flexible work and entertainment configuration.
*Smart chip, no lagging or ghosting: Equipped with a smart chip to ensure stable signal transmission, avoid lagging and ghosting, and provide a smooth usage experience.
*Gold-plated interface, anti-corrosion and anti-rust: The interface part adopts gold-plated design, which effectively resists corrosion and prevents rust, prolongs the service life and ensures stable connection.
*Plug and Play: Provides a plug-and-play experience without requiring additional drivers or complex settings.
*Multi-layer shielding structure: Made of tinned copper, aluminum foil and braided mesh, it effectively shields current interference and ensures the purity of signal transmission.
*Supports the highest resolution up to 4K@144Hz and is backward compatible: Provides resolutions up to 4K and supports refresh rates up to 144Hz, while being backward compatible to meet the needs of different display devices.
*Support HDR High Dynamic Range: Provides richer, more realistic colors and contrast, enhancing the look and feel of videos and images.
*Type-C supports front and back blind plugging: The Type-C interface supports front and back double-sided plugging and unplugging, which improves the convenience of connection.
*Supports all Thunderbolt (Type C) video output interfaces: Compatible with Thunderbolt technology to achieve faster data transfer speeds and support for multiple functions.
*Supports digital audio source signal transmission and HDCP specification: It can transmit digital audio sources simultaneously and supports HDCP specification to ensure the integrity of video and audio.
*The connector's tenon design makes it easy to apply force: The connector's tenon design ensures a firm connection, and the wire can be pulled out easily by applying force.

Features of DP signal cable:

1. Audio signal: Maximum 8-channel uncompressed 192 kHz, 32-bit audio, bit rate 6.144 Mbit/s.

2. Video signal: The maximum resolution is 7680x4320.

3. Cable: The maximum length is 15 meters (50/60 Hz, 24-bit full-color 1080p image transmission), the maximum bandwidth guarantee length is 3 meters, and it is made of copper cable or optical fiber.

4. Pins: 20〈External connector〉/32〈Laptop internal connector〉

5. Signal: +3.3V

6. Maximum voltage: 16.0 V

7. Maximum current: 500mA

DP signals are not compatible with DVI or HDMI.However, dual-mode DP is designed to transmit single-link DVI or HDMI 1.2/1.4 protocols through this port, which is accomplished by using an external passive connector to select the required signal and transfer the electrical signal from the LVDS Convert to TMDS.Dual-mode DP with passive connector does not support VGA and dual-link DVI.

These ports require active connectors to convert the protocols and signals they need to output.VGA connectors can use the DP connector for power, while dual-link DVI connectors may rely onExternal power supply.

EU regulations will start in 2024 for smartphones, iPad tablets, speakers, digital cameras, headphones, game consoles, e-book readers, mice, keyboards, and other electronic products

All must adopt Type-C (USB-C) charging standards and protocols. Laptops sold in the EU in 2026 must also be equipped with Type-C (USB-C)

The connector reduces electronic waste and makes it more convenient for consumers to use.

Sales method: manufacturing, exporting
Sales target market: Global

competitive characteristics
Unique designs or logos accepted: Special designs or logos accepted
Diverse designs: King Lai Electornics Co.,Ltd. provides diverse designs for Type C male to DP male to male wiring.
Type C male to DP male to male cable accepts original factory commissioned design and manufacturing ODM
Type C male to DP male to male cables are accepted for OEM manufacturing.
