Flex-Resistant Drag Chain Cable
Passed 1 million flex tests. Highly flexible UL drag chain cable!
Flex-Resistant Cable
Specifications: Designed and manufactured with reference to various national standards
●Flexible cable.
●Optimum for use in moving parts. (Refer to the flex characteristics below.)
●Can also be used in oil-resistant environments.
●Sheathed in heat-resistant, non-migrating PVC, ideal for environments using industrial machinery.
Applications: Suitable for applications requiring flex, vibration, and movement resistance
Ratings: Temperatures of 80°C and 105°C
Voltage: 300V and 600V
Construction: Conductor: Soft bare copper wire or tinned copper wire
Gauges: 14AWG to 28AWG
Insulation: SR-PVC, PE, etc.
Insulation: Copper braid with single or double shielded ground wire
Note: Oxygen-free copper offers high purity and a flexible, flex-resistant conductor for easy installation.
Property testing was performed before flexing.
Please understand that testing during flexing was not performed.
・Appearance and specifications are subject to change without notice.
Safety/Quality Approvals: Quality system meets ISO 9002 standard & UL verification
